The four-piston drilling pump FMC E0413 P510199 (236318001) is designed for pumping drilling mud and water, used in horizontal and vertical drilling, water drilling, as well as in irrigation systems in agricultural enterprises. The maximum pump capacity is 78 l / min, and the maximum pressure is 38 bar. The pump cylinders are made of ceramic with the addition of zirconium dioxide, which significantly increases reliability and increases the service interval. The mud pump pistons are made of high-strength rubber. The pump is equipped with stainless steel disc valves. The pump cylinder diameter can be changed to 1.625 inches (41.275 mm), 1.375 inches (34.925 mm), 1.250 inches (31.75) to change the pump's pressure and fluid delivery parameters
Specifications
HDD
Abmessungen und Gewicht
